Engine and transmission Displacement 1671.6 ccm (102.00 cubic inches) Engine type V2, four-stroke Engine details 48-degree V-twin. Hydraulic valve lifters driven by twin camshafts . Bore x stroke 97.0 x 113.0 mm (3.8 x 4.4 inches) Valves per cylinder 4 Fuel system Injection Fuel control Overhead Valves (OHV) Ignition TCI: Transistor Controlled Ignition Lubrication system Dry sump Cooling system Air Gearbox 5-speed Transmission type Belt (final drive) Fuel consumption 6.53 litres/100 km (15.3 km/l or 36.02 mpg) Greenhouse gases 151.5 CO2 g/km. (CO2 - Carbon dioxide emission) Chassis, suspension, brakes and wheels Frame type Steel Rake (fork angle) 29.0° Trail 102 mm (4.0 inches) Front suspension 43mm fork Front wheel travel 140 mm (5.5 inches) Rear suspension Single shock Rear wheel travel 109 mm (4.3 inches) Front tire 130/90-16 Rear tire 150/80-16 Front brakes Double disc Diameter 298 mm (11.7 inches) Rear brakes Single disc Diameter 320 mm (12.6 inches) Wheels Spoke Physical measures and capacities Weight incl. oil, gas, etc 351.1 kg (774.0 pounds) Seat height 709 mm (27.9 inches) If adjustable, lowest setting. Overall height 1501 mm (59.1 inches) Overall length 2499 mm (98.4 inches) Overall width 980 mm (38.6 inches) Ground clearance 145 mm (5.7 inches) Wheelbase 1689 mm (66.5 inches) Fuel capacity 17.94 litres (4.74 US gallons)
